L272D

SKU: 82783

Manufacturer: STMicroelectronics

Op Amp Dual GP ±14V/28V 16-Pin SO N Tube

5760 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.33.00.01
Automotive	No
PPAP	No
Type	General Purpose Amplifier
Manufacturer Type	General Purpose Amplifier
Number of Channels per Chip	2
Process Technology	Bipolar
Maximum Input Offset Voltage (mV)	60@24V
Minimum Single Supply Voltage (V)	4
Typical Single Supply Voltage (V)	5
Maximum Single Supply Voltage (V)	28
Minimum Dual Supply Voltage (V)	±2
Typical Dual Supply Voltage (V)	±3
Maximum Dual Supply Voltage (V)	±14
Maximum Input Offset Current (uA)	0.25@24V
Maximum Input Bias Current (uA)	2.5@24V
Typical Output Current (mA)	1000
Power Supply Type	Single
Maximum Power Dissipation (mW)	5000
Typical Slew Rate (V/us)	1@24V
Typical Voltage Gain (dB)	70
Minimum CMRR (dB)	60
Minimum CMRR Range (dB)	60 to 65
Typical Gain Bandwidth Product (MHz)	0.35
Shut Down Support	No
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tube
Pin Count	16
Standard Package Method	SOP
Original Package	SO N
Terminal Form	Surface Mount
Package Height	1.6(Max)
Package Length	10(Max)
Package Width	4(Max)
PCB changed	16
