VRF152

SKU: 93160

Manufacturer: Microchip Technology

Trans RF MOSFET N-CH 130V 20A 4-Pin Style M-174 Box

1090 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.29.00.95
Automotive	No
PPAP	No
Body Material	Si
Configuration	Single Dual Source
Channel Mode	Depletion
Channel Type	N
Number of Elements per pcs	1
Maximum Drain Source Voltage (V)	130
Maximum Gate Source Voltage (V)	±40
Maximum VSWR	30
Maximum Continuous Drain Current (A)	20
Maximum Drain Source Resistance (mOhm)	200@10V
Typical Input Capacitance @ Vds (pF)	383@50V
Typical Reverse Transfer Capacitance @ Vds (pF)	20@50V
Typical Output Capacitance @ Vds (pF)	215@50V
Typical Forward Transconductance (S)	6.2
Maximum Power Dissipation (mW)	300000
Output Power (W)	150
Typical Power Gain (dB)	22
Maximum Frequency (MHz)	175
Typical Drain Efficiency (%)	50
Operating Temperature-Min	-65
Operating Temperature-Max	200
Packing Method	Box
Original Package	Style M-174
Pin Count	4
Terminal Form	Screw
Package Height	7.11(Max)
Package Length	24.89(Max)
Package Width	12.83(Max)
