PDB181-K420K-103B

SKU: 120000

Manufacturer: Bourns

Res Carbon Film POT 10K Ohm 20% 0.2W(1/5W) 1(Elec)/1(Mech)Turns 6mm (29.5 X 17 X 21mm) Pin Panel Mount/Through Hole Automotive

1930 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8533.40.80.70
Automotive	Unknown
PPAP	Unknown
Type	Potentiometer
Resistance Value (Ohm)	10K
Tolerance	20%
Voltage Rating-Max (V)	200
Power Rating (W)	0.2 (1/5)
Technology	Carbon Film
Operating Temperature-Min	-10
Operating Temperature-Max	50
Linear or Logarithmic	Lin
Terminal Form	Pin
Positions of Adjustment	Side
Shaft Diameter (mm)	6
Number of Turns (Turns)	1(Elec)
Number of Elements	1
Number of Electrical Turns (Turns)	1
Mechanical Rotation (°)	300
Mechanical Rotational Life (Cycles)	15000
Number of Mechanical Turns (Turns)	1
Length (mm)	29.5
Depth (mm)	17
Height (mm)	21
