YC324-JK-0733RL

SKU: 150028

Manufacturer: Yageo

Res Thick Film Array 33 Ohm 5% ±200ppm/°C ISOL Epoxy 8-Pin 2012(4 X 1206) Convex SMD Automotive T/R

1320 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8533.21.00.20
Automotive	Yes
PPAP	Yes
Type	Array
Number of Resistors	4
Resistance Value (Ohm)	33
Tolerance	5%
Voltage Rating-Max (V)	200
Power Rating per Resistor (W)	0.125 (1/8)
Technology	Thick Film
Operating Temperature-Min	-55
Operating Temperature-Max	155
Temperature Coefficient (ppm/°C)	±200
Temperature Range @ Derated Power (°C)	70 to 155
Circuit Designator	ISOL
Special Features	High Reliability
Case Style	Epoxy
Case Size	2012
Case Size per Element	1206
Terminal Form	Convex
Number of Terminals	8
Terminal Pitch (mm)	1.27
Packing Method	Tape and Reel
Package Type	SMD
Package Shape	Rectangular
Case Code - in	2012(4 X 1206)
Length (mm)	5.08
Depth (mm)	3.2
Height (mm)	0.6
