HWS300-24/HD TDK-Lambda

HWS300-24/HD

SKU: 143653

Manufacturer: TDK-Lambda

AC/DC Power Supply Single-OUT 24V 14A 336W

Download sample

Request Free Samples

1090 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8504.40.60.18
Automotive	No
PPAP	No
Type	Regulated
Style	Open Frame
Input/Output Type	AC/DC
Number of Outputs	1
Output Type	Fixed
Output Voltage (V)	24
Output Current (A)	14
Output Power (W)	336
Minimum AC Input Voltage (V)	85
Maximum AC Input Voltage (V)	265
Minimum DC Input Voltage (V)	120
Maximum DC Input Voltage (V)	330
Minimum Isolation Voltage	3000VAC
Line Regulation	96mV
Load Regulation	144mV
Maximum Input Current (A)	4.1(Typ)
Input Frequency (Hz)	47 to 63
Efficiency (%)	85(Typ)
Configurable	No
Input Connector Type	Screw Terminal Block
Output Connector Type	Screw Terminal Block
Power Indicator	Yes
Ripple & Noise	150mV
Medical	No
Operating Temperature-Min	-10
Operating Temperature-Max	71
Product Weight (g)	1000
Terminal Form	Chassis
Package Height	82.04
Package Length	165.1
