CC-25-2403SR-E TDK-Lambda

CC-25-2403SR-E

SKU: 11072

Manufacturer: TDK-Lambda

Module DC-DC 24VIN 1-OUT 3.3V 7.5A 25W 7-Pin PDIP SMD

Download sample

Request Free Samples

1990 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	No
PPAP	No
Type	Step Down
Number of Outputs	1
Isolation	Isolated
Minimum Input Voltage (V)	18
Typical Input Voltage (V)	24
Maximum Input Voltage (V)	36
Output Voltage (V)	3.3
Output Current (A)	7.5
Output Power (W)	25
Minimum Isolation Voltage	500VAC
Input/Output Type	DC/DC
Switching Regulator	No
Load Regulation	200mV
Line Regulation	30mV
Efficiency (%)	90(Typ)
On/Off Logic	Positive
Operating Temperature-Min	-40
Operating Temperature-Max	85
Product Weight (g)	20
Output Type	Fixed
Original Package	PDIP SMD
Pin Count	7
Standard Package Method	DIP
Terminal Form	Surface Mount
Package Height	7.49
Package Length	43.2
Package Width	44.91
PCB changed	7
