HKQ0603S10NH-T

SKU: 61544

Manufacturer: Taiyo Yuden

Inductor High Frequency Chip Multi-Layer 0.01uH 3% 500MHz 13Q-Factor Ceramic 0.16A 0.85Ohm DCR 0201 T/R

2290 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	LTB
Automotive	No
PPAP	No
Type	High Frequency Chip
Technology	Multi-Layer
Core Body Material	Ceramic
Inductance (H)	0.01u
Tolerance	3%
Inductance Test Frequency (Hz)	500M
Maximum DC Current (A)	0.16
Maximum DC Resistance (Ohm)	0.85
Minimum Quality Factor	13
Quality Test Frequency (Hz)	500M
Minimum Self Resonant Frequency (Hz)	3800M
Number of Terminals	2
Case Size	0201
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	0.63
Depth (mm)	0.33
