STW70N60M2-4

SKU: 149348

Manufacturer: STMicroelectronics

Trans MOSFET N-CH 600V 68A 4-Pin(4+Tab) TO-247 Tube

4400 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Product Category	Power MOSFET
Configuration	Single Dual Source
Channel Mode	Enhancement
Channel Type	N
Number of Elements per pcs	1
Maximum Drain Source Voltage (V)	600
Maximum Gate Source Voltage (V)	±25
Maximum Continuous Drain Current (A)	68
Maximum Drain Source Resistance (mOhm)	40@10V
Typical Gate Charge @ Vgs (nC)	118@10V
Typical Gate Charge @ 10V (nC)	118
Typical Input Capacitance @ Vds (pF)	5200@100V
Maximum Power Dissipation (mW)	450000
Typical Fall Time (ns)	9
Typical Rise Time (ns)	10
Typical Turn-Off Delay Time (ns)	150
Typical Turn-On Delay Time (ns)	30
Operating Temperature-Min	-55
Operating Temperature-Max	150
Original Package	TO-247
Pin Count	4
Standard Package Method	TO-247
Terminal Form	Through Hole
Package Height	21
Package Length	15.8
Package Width	5
PCB changed	4
Tab	Tab
