D1D20

SKU: 30261

Manufacturer: Sensata Technologies

Solid State Relay 15mA 32V DC-IN 20A 100V DC-OUT 4-Pin

2540 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Input Type	DC
Minimum Input Voltage (V)	3.5
Maximum Input Voltage (V)	32
Maximum Input Current (mA)	15
Maximum Output Voltage (V)	100
Maximum Output Current (A)	20
Output Device	MOSFET
Output Type	DC
Minimum Load Current (mA)	1
I/O Isolation Voltage (V)	3750(RMS)
Peak Non-Repetitive Surge Current (A)	42
Maximum Off-State Leakage Current (uA)	300
Typical Input to Output Capacitance (pF)	8(Max)
Maximum Turn-On Time (ms)	0.1
Maximum Turn-Off Time (ms)	0.1
Circuit Arrangement	1 Form A
Operating Temperature-Min	-40
Operating Temperature-Max	100
Pin Count	4
Terminal Form	Screw
Package Height	22.6
Package Length	57.3
Package Width	44.5
