CES-110-01-T-S

SKU: 138654

Manufacturer: Samtec

Conn Socket Strip SKT 10 POS 2.54mm Solder ST Top Entry Thru-Hole Tube

1500 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8536.69.40.40
Automotive	No
PPAP	No
Type	Socket Strip
Gender	SKT
Number of Contacts	10
Number of Rows	1
Termination Method	Solder
Terminal Pitch (mm)	2.54
Body Orientation	Straight
Current Rating-Max(A)	5.5/Contact
Voltage Rating-Max	400VAC
Maximum Contact Resistance (mOhm)	10
Operating Temperature-Min	-55
Operating Temperature-Max	105
Packing Method	Tube
Length (mm)	25.4
Depth (mm)	3.05
Height (mm)	5.08
Tail Length (mm)	3.25
