MS24264R16B24PN

SKU: 101431

Manufacturer: RMS Connectors

Conn Circular PIN 24 POS Crimp ST Flange Mount 24 Terminal 1 Port Medical

3980 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Supplier Unconfirmed
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Military Standard	MIL-C-26500
Type	Circular
Gender	RCP
Terminal Form	Flange Mount
Body Orientation	Straight
Polarization	N
Number of Ports	1
Number of Contacts	24
Number of Terminals	24
Contact Gender	PIN
Termination Method	Crimp
Shell Size / Insert Arrangement	16-24
Wire Size (AWG)	20-24
Less Contact	No
Contact Body Material	Copper Alloy
Contact Plating	Gold
Shell Body Material	Aluminum
Current Rating-Max(A)	7.5
Operating Temperature-Min	-55
Operating Temperature-Max	200
Insulation Resistance (MOhm)	5000
Mating Style	Bayonet Lock
Mating Cycle (Cycles)	500
Length (mm)	35.73
Depth (mm)	31.75
