MS24266R12B12P6

SKU: 122743

Manufacturer: Cinch Connectivity Solutions

Conn Circular PIN 12 POS Crimp ST Cable Mount 12 Terminal 1 Port Medical

3690 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Supplier Unconfirmed
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Military Standard	MIL-C-26500
Type	Circular
Gender	PL
Terminal Form	Cable Mount
Body Orientation	Straight
Polarization	6
Number of Ports	1
Number of Contacts	12
Number of Terminals	12
Contact Gender	PIN
Termination Method	Crimp
Shell Size / Insert Arrangement	12-12
Wire Size (AWG)	20-24
Less Contact	No
Shell Body Material	Aluminum
Current Rating-Max(A)	7.5
Operating Temperature-Min	-55
Operating Temperature-Max	200
Insulation Resistance (MOhm)	5000
Mating Style	Bayonet Lock
Mating Cycle (Cycles)	500
Product Diameter (mm)	27.38
