LQH32PN1R0NNCL

SKU: 122546

Manufacturer: Panasonic

Inductor Power Chip Shielded Wirewound 1uH 30% 1MHz Ferrite 2.5A 0.0432Ohm DCR 1210 T/R

2690 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Type	Power Chip
Technology	Wirewound
Protection Style	Shielded
Core Body Material	Ferrite
Inductance (H)	1u
Tolerance	30%
Inductance Test Frequency (Hz)	1M
Maximum DC Current (A)	2.5
Maximum Saturation Current (A)	3
Maximum DC Resistance (Ohm)	0.0432
Minimum Self Resonant Frequency (Hz)	100M
Number of Terminals	2
Case Size	1210
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tape and Reel
Length (mm)	3.5
Depth (mm)	2.7
