CAT28F001GI-12T

SKU: 143423

Manufacturer: onsemi

Flash Parallel 5V 1M-bit 128K x 8 120ns 32-Pin PLCC Tray

2820 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8542.32.00.71
Automotive	No
PPAP	No
Chip Density (bit)	1M
Architecture	Sectored
Boot Block	Yes
Block Organization	Asymmetrical
Location of Boot Block	Top
Address Bus Width (bit)	17
Sector Size	4Kbyte x 2
Number of Bits/Word (bit)	8
Number of Words	128K
Programmability	Yes
Timing Type	Asynchronous
Max. Access Time (ns)	120
Maximum Erase Time (s)	65/Chip
Maximum Programming Time (ms)	8380/Chip
OE Access Time (ns)	50
Interface Type	Parallel
Operating Supply Voltage-Min (V)	4.5
Typical Operating Supply Voltage (V)	5
Operating Supply Voltage-Max (V)	5.5
Programming Voltage (V)	11.4 to 12.6
Operating Current (mA)	30
Program Current (mA)	20
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Command Compatible	No
ECC Support	No
Support of Page Mode	No
Packing Method	Tray
Pin Count	32
Standard Package Method	LCC
Original Package	PLCC
Terminal Form	Surface Mount
Package Height	2.8(Max)
Package Length	14.04(Max)
Package Width	11.5(Max)
PCB changed	32
