M2012TXG13

SKU: 41414

Manufacturer: NKK Switches

Switch Rocker ON None ON SPDT PC Pins 0.1A 28VAC 28VDC 0.4VA 50000Cycles

1600 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Pole Throw Configuration	SPDT
Switch Configuration	ON None ON
Current Rating-Max(A)	0.1@28VAC 28VDC
Maximum Power Rating (VA)	0.4@28VAC 28VDC
Dielectric Strength	1000VAC
Minimum Insulation Resistance (MOhm)	1000
Maximum Contact Resistance (mOhm)	20
Electrical Life (Cycles)	50000
Mechanical Life (Cycles)	50000
Number of Rows	1
Terminal Form	Bracket Mount/Through Hole
Terminal Form	PC Pins
Number of Terminals	3
Terminal Length (mm)	6.35
Terminal Pitch (mm)	4.7
Seal Location	Terminals
Seal Description	Epoxy
Body Orientation	Straight
Operating Temperature-Min	-30
Operating Temperature-Max	85
Body Length (mm)	16.3
Body Depth (mm)	8
