1410454C

SKU: 7154

Manufacturer: Murata Power Solutions

Inductor General Purpose Unshielded Bobbin Core 100uH 10% 1KHz 24Q-Factor 5.4A 0.046Ohm DCR RDL Carton

1440 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.50.80.00
Automotive	No
PPAP	No
Type	General Purpose
Technology	Bobbin Core
Protection Style	Unshielded
Inductance (H)	100u
Tolerance	10%
Inductance Test Frequency (Hz)	1K
Maximum DC Current (A)	5.4
Maximum Saturation Current (A)	5.4
Maximum DC Resistance (Ohm)	0.046
Minimum Quality Factor	24(Typ)
Quality Test Frequency (Hz)	100K
Minimum Self Resonant Frequency (Hz)	4.6M(Typ)
Terminal Form	Through Hole
Lead Style	Radial
Terminal Pitch (mm)	23.6
Number of Terminals	2
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Carton
Length (mm)	27.9
Depth (mm)	25.9
