EU RoHS
|
Compliant |
ECCN (US)
|
EAR99 |
Part Status
|
Active |
Automotive
|
No |
PPAP
|
No |
Type
|
Differential Line Driver |
Number of Elements per pcs
|
2 |
Number of Channels per Chip
|
1 |
Maximum Voltage Gain Range (dB)
|
<35 |
Maximum Voltage Gain (dB)
|
25.105(Typ) |
Minimum PSRR (dB)
|
20(Typ) |
Typical Output Current (mA)
|
2000@18V |
Operating Supply Voltage-Max (V)
|
20 |
Maximum Supply Voltage Range (V)
|
20 to 30 |
Minimum Single Supply Voltage (V)
|
8 |
Typical Single Supply Voltage (V)
|
9 |
Maximum Single Supply Voltage (V)
|
20 |
Maximum Input Resistance (MOhm)
|
0.02(Typ)@18V |
Maximum Power Dissipation (mW)
|
2666.7 |
Operating Temperature-Min
|
-40 |
Operating Temperature-Max
|
85 |
Supplier Temperature Grade
|
Extended |
Power Supply Type
|
Single |
Pin Count
|
20 |
Standard Package Method
|
QFN |
Original Package
|
TQFN EP |
Terminal Form
|
Surface Mount |
Package Height
|
0.73 |
Package Length
|
4 |
Package Width
|
4 |
PCB changed
|
20 |
