SP3530-01UTG Littelfuse

SP3530-01UTG

SKU: 85396

Manufacturer: Littelfuse

ESD Suppressor Diode TVS Uni-Dir 7V Automotive 2-Pin DFN T/R

Download sample

Request Free Samples

3720 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.80
Automotive	Yes
PPAP	Unknown
Type	TVS
Configuration	Single
Direction Type	Uni-Directional
Number of Elements per pcs	1
Maximum Working Voltage (V)	7
Maximum Clamping Voltage (V)	11.8(Typ)
Maximum Peak Pulse Current (A)	2.5
Maximum Leakage Current (uA)	1
Test Current (mA)	1
Operating Temperature-Min	-40
Operating Temperature-Max	125
Supplier Temperature Grade	Automotive
Packing Method	Tape and Reel
Original Package	DFN
Pin Count	2
Terminal Form	Surface Mount
Package Height	0.26
Package Length	0.6
Package Width	0.3
