IPW60R040C7

SKU: 115278

Manufacturer: Infineon Technologies AG

Trans MOSFET N-CH 600V 50A 3-Pin(3+Tab) TO-247 Tube

1060 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
Product Category	Power MOSFET
Configuration	Single
Process Technology	CoolMOS C7
Channel Mode	Enhancement
Channel Type	N
Number of Elements per pcs	1
Maximum Drain Source Voltage (V)	600
Maximum Gate Source Voltage (V)	20
Maximum Gate Threshold Voltage (V)	4
Maximum Continuous Drain Current (A)	50
Maximum Gate Source Leakage Current (nA)	100
Maximum IDSS (uA)	1
Maximum Drain Source Resistance (mOhm)	40@10V
Typical Gate Charge @ Vgs (nC)	107@10V
Typical Gate Charge @ 10V (nC)	107
Typical Input Capacitance @ Vds (pF)	4340@400V
Maximum Power Dissipation (mW)	227000
Typical Fall Time (ns)	3.2
Typical Rise Time (ns)	11
Typical Turn-Off Delay Time (ns)	81
Typical Turn-On Delay Time (ns)	18.5
Operating Temperature-Min	-55
Operating Temperature-Max	150
Packing Method	Tube
Original Package	TO-247
Pin Count	3
Standard Package Method	TO-247
Terminal Form	Through Hole
Package Height	20.95
Package Length	15.9
Package Width	5.03
PCB changed	3
Tab	Tab
