BGA614E6327

SKU: 152612

Manufacturer: Infineon Technologies AG

RF Amp Single MMIC Amp 4-Pin(3+Tab) SOT-343 T/R

2910 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
Part Status	Obsolete
Automotive	No
PPAP	No
Manufacturer Type	MMIC Amplifier
Number of Channels per Chip	1
Typical 3dB Bandwidth (MHz)	2700
Typical Power Gain (dB)	15.9@2200MHz
Typical Output Power (dBm)	12.6@2200MHz
Typical Output Intercept Point (dBm)	20.8@2200MHz
Maximum Reverse Isolation (dB)	20.6@2200MHz
Maximum Input Return Loss (dB)	13.7@2200MHz
Maximum Output Return Loss (dB)	16@2200MHz
Typical Noise Figure (dB)	2.32@2200MHz
Typical Single Supply Voltage (V)	5
Maximum Supply Current (mA)	41.2
Power Supply Type	Single
Packing Method	Tape and Reel
Original Package	SOT-343
Pin Count	4
Standard Package Method	SOT-343
Terminal Form	Surface Mount
Package Height	0.9(Max)
Package Length	2
Package Width	1.25
PCB changed	3
Tab	Tab
