MPSA44

SKU: 105549

Manufacturer: Diotec Semiconductor AG

Trans GP BJT NPN 400V 0.3A 625mW 3-Pin TO-92 Ammo

1760 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Type	NPN
Product Category	Bipolar Small Signal
Body Material	Si
Configuration	Single
Number of Elements per pcs	1
Collector Base Voltage-Max (V)	500
Collector-Emitter Voltage-Max (V)	400
Maximum Emitter Base Voltage (V)	6
Maximum Base Emitter Saturation Voltage (V)	0.75@1mA@10mA
Maximum Collector-Emitter Saturation Voltage (V)	0.75@5mA@50mA
Maximum DC Collector Current (A)	0.3
Maximum Collector Cut-Off Current (nA)	100
Minimum DC Current Gain	40@100mA@10V
Maximum Power Dissipation (mW)	625
Operating Temperature-Min	-55
Operating Temperature-Max	150
Packing Method	Ammo
Original Package	TO-92
Pin Count	3
Standard Package Method	TO-92
Terminal Form	Through Hole
PCB changed	3
