DGD0547FN-7

SKU: 11407

Manufacturer: Diodes Incorporated

Driver 2-OUT High and Low Side Half Brdg 10-Pin WDFN EP T/R

3830 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	No
PPAP	No
Driver Type	High and Low Side
Bridge Type	Half Bridge
Number of Drivers	2
High and Low Sides Dependency	Synchronous
Type	MOSFET
Number of Outputs	2
Maximum Rise Time (ns)	30
Maximum Fall Time (ns)	25
Maximum Propagation Delay Time (ns)	56
Input Logic Compatibility	TTL
Operating Supply Voltage-Min (V)	5
Operating Supply Voltage-Max (V)	14
Maximum Supply Current (mA)	7.3(Typ)
Typical Input Low Threshold Voltage (V)	0.8(Max)
Typical Input High Threshold Voltage (V)	2.4(Min)
Maximum Power Dissipation (mW)	400
Operating Temperature-Min	-40
Operating Temperature-Max	125
Supplier Temperature Grade	Extended
Special Features	Under Voltage Lockout
Maximum Turn-On Delay Time (ns)	5
Maximum Turn-Off Delay Time (ns)	5
Latch-Up Proof	No
Packing Method	Tape and Reel
Original Package	WDFN EP
Pin Count	10
Terminal Form	Surface Mount
Package Height	0.73
Package Length	3
Package Width	3
