BZT52C2V0TQ-7-F

SKU: 16031

Manufacturer: Diodes Incorporated

Zener Diode Single 2V 5% 100Ohm 300mW Automotive 2-Pin SOD-523 T/R

2020 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.50
Automotive	Yes
PPAP	Yes
Type	Voltage Regulator
Configuration	Single
Nominal Zener Voltage (V)	2
Zener Voltage Tolerance	5%
Maximum Forward Voltage (V)	0.9
Maximum Power Dissipation (mW)	300
Test Current (mA)	5
Maximum Reverse Leakage Current (uA)	150
Maximum Zener Impedance (Ohm)	100
Maximum Power Dissipation @ 25C (mW)	300
Operating Temperature-Min	-65
Operating Temperature-Max	150
Supplier Temperature Grade	Automotive
Typical Voltage Temperature Coefficient	-1.75mV/°C
Packing Method	Tape and Reel
Original Package	SOD-523
Pin Count	2
Standard Package Method	SOD
Terminal Form	Surface Mount
Package Height	0.65(Max)
Package Length	1.25(Max)
Package Width	0.85(Max)
