PDS1-S24-S5-S CUI Inc

PDS1-S24-S5-S

SKU: 144048

Manufacturer: CUI Inc

Module DC-DC 24VIN 1-OUT 5V 0.2A 1W 4-Pin SIP Module

Request Free Samples

3300 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Type	Step Down
Number of Outputs	1
Isolation	Isolated
Minimum Input Voltage (V)	21.6
Typical Input Voltage (V)	24
Maximum Input Voltage (V)	26.4
Output Voltage (V)	5
Output Current (A)	0.2
Output Power (W)	1
Minimum Isolation Voltage	1500VDC
Switching Frequency (kHz)	100(Typ)
Switching Regulator	Yes
Load Regulation	12%(Typ)
Line Regulation	1.2%
Efficiency (%)	80(Typ)
Operating Temperature-Min	-40
Operating Temperature-Max	105
Supplier Temperature Grade	Extended
Output Type	Fixed
Original Package	SIP Module
Pin Count	4
Standard Package Method	SIM
Terminal Form	Through Hole
Package Height	10.16
Package Length	11.6
Package Width	6
PCB changed	4
