CG2164X3-C2

SKU: 143445

Manufacturer: California Eastern Laboratories

RF Switch DPDT 50MHz to 6GHz 12dB 6-Pin XSON EP T/R

1160 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Switch Type	DPDT
Switch Configuration	Single DPDT
Number of Switches	1
Switching Speed (ns)	30(Typ)
Frequency Band (MHz)	50 to 6000
Maximum Frequency (MHz)	6000
Minimum Isolation Voltage (dB)	12
Maximum Insertion Loss (dB)	1
Technology	GaAs MMIC
High Control Voltage (V)	1.8 to 5
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Original Package	XSON EP
Pin Count	6
Terminal Form	Surface Mount
Package Height	0.37
Package Length	1.5
Package Width	1.5
