HMC1099PM5E

SKU: 86959

Manufacturer: Analog Devices

RF Amp Single Power Amp 1.1GHz 32V 32-Pin LFCSP EP Tray

2330 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Manufacturer Type	Power Amplifier
Number of Channels per Chip	1
Maximum Operating Frequency (MHz)	1100
Typical Gain Flatness (dB)	1
Typical Power Gain (dB)	18@1100MHz
Typical Output Power (dBm)	41.5@1100MHz
Typical Output Intercept Point (dBm)	45@1100MHz
Maximum Input Return Loss (dB)	12(Typ)@1100MHz
Maximum Output Return Loss (dB)	17(Typ)@1100MHz
Typical Noise Figure (dB)	5@1100MHz
Maximum Input VSWR	6
Maximum Output VSWR	6
Operating Supply Voltage-Max (V)	32
Minimum Single Supply Voltage (V)	24
Typical Single Supply Voltage (V)	28
Maximum Single Supply Voltage (V)	32
Power Supply Type	Single
Maximum Power Dissipation (mW)	21210
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tray
Original Package	LFCSP EP
Pin Count	32
Standard Package Method	CSP
Terminal Form	Surface Mount
Package Height	1.22
Package Length	5
Package Width	5
PCB changed	32
