ADUM7702-8BRIZ

SKU: 100694

Manufacturer: Analog Devices

1-Channel Single ADC Delta-Sigma 16-bit Serial 8-Pin SOIC W Tube

3720 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Converter Type	General Purpose
Architecture	Delta-Sigma
Resolution	16bit
Number of ADCs	1
Number of Input Channels	1
Digital Interface Type	Serial
Input Type	Voltage
Input Signal Type	Pseudo-Differential
Voltage Reference	Internal
Polarity of Input Voltage	Bipolar
Voltage Supply Source	Single
Input Voltage	±0.064V
Minimum Single Supply Voltage (V)	4.5
Typical Single Supply Voltage (V)	5
Maximum Single Supply Voltage (V)	5.5
Typical Power Dissipation (mW)	51
Maximum Power Dissipation (mW)	71.5
Integral Nonlinearity Error	±8LSB
Full Scale Error	±0.2%FSR
Signal to Noise Ratio	82dB(Typ)
No Missing Codes (bit)	16
Sample and Hold	No
Single-Ended Input	No
Digital Supply Support	No
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tube
Original Package	SOIC W
Pin Count	8
Standard Package Method	SOP
Terminal Form	Surface Mount
Package Height	2.35
Package Length	5.85
Package Width	7.5
PCB changed	8
