ADM8615Z050ACBZ-R7

SKU: 95371

Manufacturer: Analog Devices

Processor Supervisor 0.5V 1 Active Low/Open Drain 6-Pin WLCSP T/R

1070 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Number of Supervisors	1
Maximum Reset Active Time (ms)	200(Typ)
Output Driver	Active Low/Open Drain
Minimum Reset Threshold Voltage (V)	0.489
Typical Reset Threshold Voltage (V)	0.5
Maximum Reset Threshold Voltage (V)	0.511
Operating Supply Voltage-Min (V)	2
Operating Supply Voltage-Max (V)	5.5
Power Fail Detection	No
Watchdog Timer	Yes
Manual Reset	Yes
Chip Enable Signals	No
Battery Backup Switching	No
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Type	Voltage Supervisory
Original Package	WLCSP
Pin Count	6
Standard Package Method	BGA
Terminal Form	Surface Mount
Package Height	0.36
Package Length	1.46
Package Width	0.96
PCB changed	6
