ADG936BRUZ

SKU: 157447

Manufacturer: Analog Devices

RF Switch SPDT 0MHz to 2GHz 31dB 20-Pin TSSOP Tube

870 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Switch Type	SPDT
Switch Configuration	Dual SPDT
Number of Switches	2
Frequency Band (MHz)	0 to 2000
Maximum Frequency (MHz)	2000
Minimum Isolation Voltage (dB)	31
Maximum Insertion Loss (dB)	1.25
Technology	CMOS/LVTTL
Operating Supply Voltage-Min (V)	1.65
Typical Operating Supply Voltage (V)	1.8
Operating Supply Voltage-Max (V)	2.75
Typical Supply Current (mA)	30(Max)
Operating Temperature-Min	-40
Operating Temperature-Max	85
Supplier Temperature Grade	Industrial
Packing Method	Tube
Pin Count	20
Original Package	TSSOP
Standard Package Method	SOP
Terminal Form	Surface Mount
Package Height	1.05(Max)
Package Length	6.5
Package Width	4.4
PCB changed	20
