AOZ8831DT-03

SKU: 10578

Manufacturer: Alpha and Omega Semiconductor

ESD Suppressor Diode TVS Bi-Dir 3.6V 2-Pin DFN T/R

2440 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	Unknown
PPAP	Unknown
Type	TVS
Configuration	Single
Direction Type	Bi-Directional
Number of Elements per pcs	1
Maximum Working Voltage (V)	3.6
Maximum Clamping Voltage (V)	15
Maximum Leakage Current (uA)	0.1
Peak Pulse Power Dissipation (W)	90
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Original Package	DFN
Pin Count	2
Standard Package Method	DFN
Terminal Form	Surface Mount
Package Height	0.47
Package Length	1
Package Width	0.6
PCB changed	2
