BTA316-600B0Q

SKU: 46542

Manufacturer: WeEn Semiconductors

TRIAC Diode 600V 16A(RMS) 150A 3-Pin(3+Tab) TO-220AB Tube

1950 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
Automotive	Unknown
PPAP	Unknown
Maximum Rate of Rise of Off-State Voltage (V/us)	2500(Min)
Maximum Rate of Rise of On-State Current (A/us)	100
Maximum Gate Trigger Voltage (V)	1
Maximum Gate Trigger Current (mA)	50
Surge Current Rating (A)	150
Maximum Holding Current (mA)	60
Repetitive Peak Reverse Voltage (V)	600
Peak On-State Voltage (V)	1.5@18A
Repetitive Peak Forward Blocking Voltage (V)	600
RMS On-State Current (A)	16
Repetitive Peak Off-State Current (mA)	0.5
AC Switch	No
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tube
Original Package	TO-220AB
Pin Count	3
Terminal Form	Through Hole
Package Height	9.4(Max)
Package Length	10.3(Max)
Package Width	4.7(Max)
PCB changed	3
