EGF1THE3/67A

SKU: 110639

Manufacturer: Vishay

Diode Switching 1.3KV 1A Automotive 2-Pin DO-214BA T/R

8640 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8541.10.00.80
Automotive	Yes
PPAP	Unknown
Type	Switching Diode
Maximum DC Reverse Voltage (V)	1300
Configuration	Single
Peak Reverse Repetitive Voltage (V)	1300
Maximum Continuous Forward Current (A)	1
Peak Non-Repetitive Surge Current (A)	20
Peak Forward Voltage (V)	3
Peak Reverse Current (uA)	5
Peak Reverse Recovery Time (ns)	75(Typ)
Operating Temperature-Min	-55
Operating Temperature-Max	150
Packing Method	Tape and Reel
Supplier Temperature Grade	Automotive
Original Package	DO-214BA
Pin Count	2
Standard Package Method	DO-214-BA
Terminal Form	Surface Mount
Package Height	2.74(Max)
Package Length	4.75(Max)
Package Width	2.9(Max)
PCB changed	2
