B40C800G-E4/51

SKU: 65530

Manufacturer: Vishay

Rectifier Bridge Diode Single 65V 0.9A 4-Pin Case WOG Bulk

1590 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.80
Automotive	No
PPAP	No
Bridge Type	Single Phase
Configuration	Single
Peak Reverse Repetitive Voltage (V)	65
Peak Average Forward Current (A)	0.9@Ta=45C
Peak RMS Reverse Voltage (V)	40
Peak Non-Repetitive Forward Surge Current (A)	45
Peak Forward Voltage (V)	1
Peak Reverse Current (uA)	10
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Bulk
Original Package	Case WOG
Pin Count	4
Standard Package Method	WOG
Terminal Form	Through Hole
Package Height	5.6(Max)
Package Length	9.86(Max)
Package Width	8.84(Max)
