UCC3805N

SKU: 149867

Manufacturer: Texas Instruments

Current Mode PWM Controller 5V 1000kHz Automotive 8-Pin PDIP Tube

760 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Type	Current Mode PWM Controller
Control Method	Current
Topology	Boost
Number of PWM Outputs	1
Oscillator Accuracy (kHz)	31
Switching Frequency (kHz)	1000
Maximum Duty Cycle (%)	50
Rise Time (ns)	41
Fall Time (ns)	44
Output Voltage (V)	5
Operating Supply Voltage (V)	11(Max)
Operating Supply Voltage-Max (V)	11
Maximum Supply Current (mA)	25
Maximum Power Dissipation (mW)	1000
Adjustable Output	No
On/Off Pin	No
Synchronous Pin	No
UVLO Turn-Off Threshold (V)	3.6
UVLO Turn-On Threshold (V)	4.1
Operating Temperature-Min	0
Operating Temperature-Max	70
Packing Method	Tube
Original Package	PDIP
Pin Count	8
Standard Package Method	DIP
Terminal Form	Through Hole
Package Height	5.08(Max) - 0.51(Min)
Package Length	10.16(Max)
Package Width	6.6(Max)
PCB changed	8
