SN75240PWR

SKU: 43037

Manufacturer: Texas Instruments

ESD Suppressor Diode TVS Uni-Dir 6V 8-Pin TSSOP T/R

670 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.80
SVHC	Yes
Automotive	No
PPAP	No
Type	TVS
Configuration	Quad
Direction Type	Uni-Directional
Number of Elements per pcs	4
Maximum Working Voltage (V)	6(Min)
Minimum Breakdown Voltage (V)	6.8
Maximum Breakdown Voltage (V)	8
Maximum Leakage Current (uA)	1
Test Current (mA)	1
Maximum Power Dissipation (mW)	520
Peak Pulse Power Dissipation (W)	60
Capacitance Value (pF)	35(Typ)
Operating Temperature-Min	0
Operating Temperature-Max	70
Packing Method	Tape and Reel
Fail Safe Protection	No
Pin Count	8
Standard Package Method	SOP
Original Package	TSSOP
Terminal Form	Surface Mount
Package Height	1.05(Max)
Package Length	3.1(Max)
Package Width	4.5(Max)
PCB changed	8
