SN74S74N

SKU: 85358

Manufacturer: Texas Instruments

Flip Flop D-Type Pos-Edge 2-Element 14-Pin PDIP Tube

2860 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Logic Family	S
Logic Function	D-Type
Number of Channels per Chip	2
Number of Elements per pcs	2
Number of Element Inputs	1
Number of Element Outputs	1
Bus Hold	No
Set/Reset	Set/Reset
Polarity	Inverting/Non-Inverting
Triggering Type	Positive-Edge
Maximum Propagation Delay Time @ Maximum CL (ns)	9@5V
Absolute Propagation Delay Time (ns)	13.5
Process Technology	Bipolar
Input Signal Type	Single-Ended
Maximum Low Level Output Current (mA)	20
Maximum High Level Output Current (mA)	-1
Operating Supply Voltage-Min (V)	4.75
Typical Operating Supply Voltage (V)	5
Operating Supply Voltage-Max (V)	5.25
Propagation Delay Test Condition (pF)	15
Operating Temperature-Min	0
Operating Temperature-Max	70
Supplier Temperature Grade	Commercial
Packing Method	Tube
Standard Package Method	DIP
Pin Count	14
Original Package	PDIP
Terminal Form	Through Hole
Package Height	5.08(Max) - 0.51(Min)
Package Length	19.69(Max)
Package Width	6.6(Max)
PCB changed	14
