SN74LS283NS

SKU: 85309

Manufacturer: Texas Instruments

Binary Full Adder Single-Element 4-Bit 16-Pin SOP Tube

2550 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Unconfirmed
Automotive	No
PPAP	No
Logic Family	LS
Logic Function	Binary Full Adder
Number of Elements per pcs	1
Number of Bits	4
Maximum Propagation Delay Time @ Maximum CL (ns)	24@5V
Absolute Propagation Delay Time (ns)	24
Process Technology	Bipolar
Maximum Low Level Output Current (mA)	8
Maximum High Level Output Current (mA)	-0.4
Operating Supply Voltage-Min (V)	4.75
Typical Operating Supply Voltage (V)	5
Operating Supply Voltage-Max (V)	5.25
Propagation Delay Test Condition (pF)	15
Maximum Power Dissipation (mW)	95(Typ)
Operating Temperature-Min	0
Operating Temperature-Max	70
Supplier Temperature Grade	Commercial
Packing Method	Tube
Pin Count	16
Original Package	SOP
Standard Package Method	SOP
Terminal Form	Surface Mount
Package Height	1.85(Max)
Package Length	10.5(Max)
Package Width	5.6(Max)
PCB changed	16
