ISO124U/1K

SKU: 146481

Manufacturer: Texas Instruments

SP Amp ISOL Amp Single ±18V 8-Pin SOIC T/R

6070 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.33.00.01
SVHC	Yes
Automotive	No
PPAP	No
Type	Isolation Amplifier
Number of Elements per pcs	1
Number of Channels per Chip	1
Maximum Voltage Gain Range (dB)	<35
Maximum Voltage Gain (dB)	0(Typ)
Typical Output Current (mA)	15@±15V
Maximum Input Offset Voltage (mV)	50@±15V
Operating Supply Voltage-Max (V)	±18
Maximum Supply Voltage Range (V)	30 to 50
Minimum Dual Supply Voltage (V)	±4.5
Typical Dual Supply Voltage (V)	±15
Maximum Dual Supply Voltage (V)	±18
Minimum DC Continuous Isolation Voltage (V)	2400
Maximum Input Resistance (MOhm)	0.2(Typ)@5V
Operating Temperature-Min	-25
Operating Temperature-Max	85
Packing Method	Tape and Reel
Power Supply Type	Dual
Pin Count	8
Standard Package Method	SOP
Original Package	SOIC
Terminal Form	Surface Mount
Package Height	2.35(Max)
Package Length	18.1(Max)
Package Width	7.6(Max)
PCB changed	8
