INA303A1IPW

SKU: 51811

Manufacturer: Texas Instruments

Comparator Dual 5.5V 14-Pin TSSOP Tube

3770 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
SVHC	Yes
Automotive	No
PPAP	No
Manufacturer Type	General Purpose Comparator
Number of Channels per Chip	2
Rail to Rail	No
Typical CMRR (dB)	120
Typical PSRR (dB)	130.46
Maximum Propagation Delay Time (ns)	2000
Output Type	Open Drain
Operating Supply Voltage-Max (V)	5.5
Maximum Input Offset Voltage (mV)	0.08@5V
Minimum Single Supply Voltage (V)	2.7
Typical Single Supply Voltage (V)	5
Maximum Single Supply Voltage (V)	5.5
Typical Voltage Gain (dB)	26.02
Typical Voltage Gain Range (dB)	<40
Maximum Input Bias Current (uA)	115(Typ)@5V
Maximum Quiescent Current (mA)	0.95@5V
Maximum Test Temperature (°C)	125
Minimum Test Temperature (°C)	-40
Power Supply Type	Single
Operating Temperature-Min	-40
Operating Temperature-Max	125
Supplier Temperature Grade	Extended
Packing Method	Tube
Standard Package Method	SOP
Original Package	TSSOP
Pin Count	14
Terminal Form	Surface Mount
Package Height	1.05(Max)
Package Length	5.1(Max)
Package Width	4.5(Max)
PCB changed	14
