CD4522BM

SKU: 122156

Manufacturer: Texas Instruments

Counter/Divider Single 4-Bit Decade Down 16-Pin SOIC Tube

890 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
SVHC	Yes
Automotive	No
PPAP	No
Type	Decade
Logic Family	CD4000
Logic Function	Counter/Divider
Operation Mode	Down Counter
Number of Elements per pcs	1
Number of Element Inputs	4
Number of Count Input Enables	0
Number of Selection Inputs per Element	0
Number of Element Outputs	4
Number of Stages	4
Reset Type	Asynchronous
Direction Type	Uni-Directional
Triggering Type	Positive-Edge/Negative-Edge
Maximum Propagation Delay Time @ Maximum CL (ns)	1100@5V
Absolute Propagation Delay Time (ns)	1100
Process Technology	CMOS
Operating Supply Voltage-Min (V)	3
Typical Operating Supply Voltage (V)	3.3
Operating Supply Voltage-Max (V)	18
Maximum Quiescent Current (mA)	0.1
Propagation Delay Test Condition (pF)	50
Parallel Enable Input	Yes
Terminal Count Output	Yes
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tube
Pin Count	16
Original Package	SOIC
Standard Package Method	SOP
Terminal Form	Surface Mount
Package Height	1.5(Max)
Package Length	10(Max)
Package Width	4(Max)
PCB changed	16
