CD40106BM

SKU: 46655

Manufacturer: Texas Instruments

Inverter Schmitt Trigger 6-Element CMOS 14-Pin SOIC Tube

2660 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Logic Family	CD4000
Logic Function	Inverter Schmitt Trigger
Number of Elements per pcs	6
Maximum Propagation Delay Time @ Maximum CL (ns)	280@5V
Absolute Propagation Delay Time (ns)	280
Process Technology	CMOS
Output Type	Schmitt Trigger
Maximum Low Level Output Current (mA)	4.2(Min)
Maximum High Level Output Current (mA)	-4.2(Min)
Minimum High Level Output Voltage (V)	4.95
Maximum Low Level Output Voltage (V)	0.05
Operating Supply Voltage-Min (V)	3
Typical Operating Supply Voltage (V)	3.3
Operating Supply Voltage-Max (V)	18
Typical Quiescent Current (uA)	0.04
Maximum Quiescent Current (uA)	20
Propagation Delay Test Condition (pF)	50
Operating Temperature-Min	-55
Operating Temperature-Max	125
Packing Method	Tube
Pin Count	14
Original Package	SOIC
Standard Package Method	SOP
Terminal Form	Surface Mount
Package Height	1.5(Max)
Package Length	8.75(Max)
Package Width	4(Max)
PCB changed	14
