5962-9557701NXD Texas Instruments

5962-9557701NXD

SKU: 24333

Manufacturer: Texas Instruments

Bus XCVR Quad 36-CH 3-ST 100-Pin LQFP Tray

Request Free Samples

2670 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Logic Family	ABT
Logic Function	Bus Transceiver
Data Flow Direction	Bi-Directional
Number of Elements per pcs	4
Number of Channels per Chip	36
Number of Selection Inputs per Element	0
Number of Output Enables per Element	1 Low
Number of Input Enables per Element	0
Number of Direction Control Inputs	1 Low/High
Bus Hold	Yes
Polarity	Non-Inverting
Absolute Propagation Delay Time (ns)	8.2
Maximum Propagation Delay Time @ Maximum CL (ns)	4.6@5V
Propagation Delay Test Condition (pF)	50
Process Technology	BiCMOS
Input Level	TTL
Output Level	TTL
Output Type	3-State
Maximum Low Level Output Current (mA)	48
Maximum High Level Output Current (mA)	-24
Maximum Quiescent Current (uA)	20000
Operating Supply Voltage-Min (V)	4.5
Operating Supply Voltage-Max (V)	5.5
Operating Temperature-Min	-55
Operating Temperature-Max	125
Supplier Temperature Grade	Military
Packing Method	Tray
Standard Package Method	QFP
Pin Count	100
Original Package	LQFP
Terminal Form	Surface Mount
Package Height	1.45(Max)
Package Length	14.2(Max)
Package Width	14.2(Max)
PCB changed	100
