T9AS5D22-110

SKU: 123011

Manufacturer: TE Connectivity

Power Relay 110VDC 20(NO)/10(NC)A SPDT(32.51mm 27.43mm 27.94mm) THT

2440 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8536.41.00.50
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Contact Arrangement	SPDT
Contact Form	1 Form C
DC Coil Voltage (V)	110
Coil Current (mA)	9
Coil Resistance (Ohm)	12.1K
Maximum Pick-Up Voltage	82.5VDC
Minimum Dropout Voltage	11VDC
Maximum AC Switching Voltage (V)	277
Maximum Switching Current (A)	20(NO)/10(NC)
Operate Time (ms)	15
LED Indicator	No
Push to Test Button	No
Coil Suppression Diode	No
Relay Construction	Non-Latching
Terminal Form	Through Hole
Terminal Form	Quick Connect/PC Pin
Number of Terminals	5
Operating Temperature-Min	-55
Operating Temperature-Max	85
Product Weight (g)	33
Length (mm)	32.51
Depth (mm)	27.43
