PAF-500F-48-28/T TDK-Lambda

PAF-500F-48-28/T

SKU: 66219

Manufacturer: TDK-Lambda

Module DC-DC 48VIN 1-OUT 28V 18A 504W 16-Pin Brick

Download sample

Request Free Samples

1440 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

QUANTITY

Increments of 0 pcs

Specifications
Contact Us

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
Automotive	No
PPAP	No
Type	Step Down
Isolation	Isolated
Number of Outputs	1
Minimum Input Voltage (V)	36
Typical Input Voltage (V)	48
Maximum Input Voltage (V)	76
Output Voltage (V)	28
Output Current (A)	18
Output Power (W)	504
Minimum Isolation Voltage	1500VDC
Input/Output Type	DC/DC
Switching Regulator	No
Load Regulation	56mV
Line Regulation	56mV
Efficiency (%)	90(Typ)
Operating Temperature-Min	-40
Operating Temperature-Max	100
Product Weight (g)	250
Output Type	Fixed
Original Package	Brick
Pin Count	16
Standard Package Method	Brick
Terminal Form	Through Hole
Package Height	12.7
Package Length	116.8
Package Width	61
PCB changed	16
