RCP1317NP-221L

SKU: 155684

Manufacturer: Sumida

Inductor Power Shielded Wirewound 220uH 15% 1KHz Ferrite 1.8A 0.278Ohm DCR RDL Box

830 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8504.50.80.00
Automotive	No
PPAP	No
Type	Power
Technology	Wirewound
Protection Style	Shielded
Core Body Material	Ferrite
Inductance (H)	220u
Tolerance	15%
Inductance Test Frequency (Hz)	1K
Maximum DC Current (A)	1.8
Maximum Saturation Current (A)	1.9
Maximum DC Resistance (Ohm)	0.278
Terminal Form	Through Hole
Lead Style	Radial
Terminal Pitch (mm)	5
Number of Terminals	2
Operating Temperature-Min	-40
Operating Temperature-Max	100
Packing Method	Box
Product Diameter (mm)	13.5
