TIP2955

SKU: 29145

Manufacturer: STMicroelectronics

Trans GP BJT PNP 60V 15A 90000mW 3-Pin(3+Tab) TO-247 Tube

44920 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8541.29.00.95
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	PNP
Product Category	Bipolar Power
Body Material	Si
Configuration	Single
Number of Elements per pcs	1
Collector Base Voltage-Max (V)	100
Collector-Emitter Voltage-Max (V)	60
Maximum Collector-Emitter Saturation Voltage (V)	1@0.4A@4A
Maximum DC Collector Current (A)	15
Minimum DC Current Gain	20@4A@4V
Maximum Power Dissipation (mW)	90000
Maximum Transition Frequency (MHz)	3(Min)
Operating Temperature-Min	-65
Operating Temperature-Max	150
Packing Method	Tube
Original Package	TO-247
Pin Count	3
Standard Package Method	TO-247
Terminal Form	Through Hole
Package Height	20.15(Max)
Package Length	15.75(Max)
Package Width	5.15(Max)
PCB changed	3
Tab	Tab
