STTH2003CG

SKU: 78421

Manufacturer: STMicroelectronics

Rectifier Diode Switching 300V 20A 35ns 3-Pin(2+Tab) D2PAK Tube

6500 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8541.10.00.80
Automotive	No
PPAP	No
Type	Switching Diode
Configuration	Dual Common Cathode
Peak Reverse Repetitive Voltage (V)	300
Maximum Continuous Forward Current (A)	20
Peak Non-Repetitive Surge Current (A)	110
Peak Forward Voltage (V)	1.25@10A
Peak Reverse Current (uA)	20
Peak Reverse Recovery Time (ns)	35
Operating Temperature-Min	-65
Operating Temperature-Max	175
Packing Method	Tube
Pin Count	3
Standard Package Method	TO-263
Original Package	D2PAK
Terminal Form	Surface Mount
Package Height	4.6(Max)
Package Length	10.28(Max)
Package Width	9.35(Max)
PCB changed	2
Tab	Tab
