SPV1020

SKU: 21717

Manufacturer: STMicroelectronics

Conv DC-DC 6.5V to 40V Step Up Single-Out 6.5V to 45V 9A 36-Pin PowerSSO EP Tube

360 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Obsolete
HTS	8542.39.00.01
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	Step Up
Output Type	Adjustable
Switching Frequency (kHz)	70 to 150
Switching Regulator	Yes
Number of Outputs	1
Output Voltage (V)	6.5 to 45
Maximum Output Current (A)	9
Minimum Input Voltage (V)	6.5
Maximum Input Voltage (V)	40
Operating Supply Voltage (V)	6.5 to 45
Typical Quiescent Current (uA)	5000
Efficiency (%)	98
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tube
Pin Count	36
Standard Package Method	PowerSSO
Original Package	PowerSSO EP
Terminal Form	Surface Mount
Package Height	2.4(Max)
Package Length	10.5(Max)
Package Width	7.6(Max)
PCB changed	36
