BD136

SKU: 46488

Manufacturer: STMicroelectronics

Trans GP BJT PNP 45V 1.5A 1250mW 3-Pin(3+Tab) SOT-32 Tube

6170 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8541.29.00.95
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	PNP
Product Category	Bipolar Power
Body Material	Si
Configuration	Single
Number of Elements per pcs	1
Collector Base Voltage-Max (V)	45
Collector-Emitter Voltage-Max (V)	45
Maximum Emitter Base Voltage (V)	5
Maximum Collector-Emitter Saturation Voltage (V)	0.5@0.05A@0.5A
Maximum DC Collector Current (A)	1.5
Maximum Collector Cut-Off Current (nA)	100
Minimum DC Current Gain	25@5mA@2V
Maximum Power Dissipation (mW)	1250
Operating Temperature-Min	-65
Operating Temperature-Max	150
Packing Method	Tube
Original Package	SOT-32
Pin Count	3
Standard Package Method	TO-126
Terminal Form	Through Hole
Package Height	10.8(Max)
Package Length	7.8(Max)
Package Width	2.7(Max)
PCB changed	3
Tab	Tab
