BAR43SFILM

SKU: 60650

Manufacturer: STMicroelectronics

Rectifier Diode Small Signal Schottky Si 30V 0.1A 5ns 3-Pin SOT-23 T/R

18430 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8541.10.00.80
Automotive	No
PPAP	No
Type	Small Signal Schottky Diode
Body Material	Si
Maximum DC Reverse Voltage (V)	30
Configuration	Dual Series
Peak Reverse Repetitive Voltage (V)	30
Maximum Continuous Forward Current (A)	0.1
Peak Non-Repetitive Surge Current (A)	0.75
Peak Forward Voltage (V)	1
Peak Reverse Current (uA)	0.5
Maximum Junction Ambient Thermal Resistance	500°C/W
Maximum Power Dissipation (mW)	250
Peak Reverse Recovery Time (ns)	5
Operating Temperature-Min	-65
Operating Temperature-Max	150
Packing Method	Tape and Reel
Pin Count	3
Standard Package Method	SOT
Original Package	SOT-23
Terminal Form	Surface Mount
Package Height	0.95
Package Length	2.9
Package Width	1.3
PCB changed	3
